Microplate Readers – AMR-100 & AMR-100T

Microplate Readers from Allsheng, available through Apex Scientific in South Africa, combine precision and reliability for scientific and clinical applications. These advanced instruments meet the standards expected from modern laboratory equipment and ensure consistent, high-quality absorbance measurements across a broad wavelength range.

Fast, Accurate, and User-Friendly Microplate Reader

The microplate reader features a 0.0–4.000 Abs range, 8-position filter wheel, and 6-second 96-well plate detection. Its 7-inch touchscreen enables easy operation without a keyboard. Built-in software with USB export and ReaderIt-I software provide efficient control and data analysis for absorbance-based applications. The AMR-100T includes incubation temperature that ranges from RT+4°C to 50°C, supporting various applications with reliable temperature regulation.

Fast Detection and Flexible Functionality

Both the AMR-100 and AMR-100T Microplate Readers feature an 8-position filter wheel equipped with four standard filters. Users can easily expand functionality by adding more filters as needed. The high-speed optical system completes 96-well microplate readings in just six seconds, dramatically improving sample throughput and overall laboratory efficiency. This fast detection capability supports busy workflows and helps maintain momentum in high-demand environments.

User-Friendly Interface and Smart Software

Designed with the user in mind, each microplate reader includes a 7-inch high-resolution color touchscreen, eliminating the need for a keyboard and simplifying device operation. The intuitive interface ensures quick learning and ease of use, even for new lab personnel. Integrated software enables straightforward instrument control and data management. Additionally, USB connectivity allows for direct data export. Both models come with Readerlt-I software, which streamlines data analysis and supports a wide variety of laboratory protocols.

Advanced Environmental Control

The AMR-100T model offers an added advantage with its incubation temperature range from RT+4 °C to 50 °C. This feature supports temperature-sensitive applications and expands the instrument’s capabilities for specific testing requirements. Whether you’re conducting ELISA assays, enzyme activity studies, or kinetic analyses, this model provides the stability and control needed for reliable results.

These microplate readers are essential tools for laboratories that prioritize accuracy, efficiency, and dependability. Their versatile design, robust performance, and user-friendly operation make them ideal for research and diagnostic settings.

Allsheng Microplate Readers: Versatile Detection Solutions for Research and Industry

Allsheng’s Microplate Reader series delivers performance and flexibility for laboratories in life sciences, medicine, pharmaceuticals, food, and cosmetics. Whether you need a single-function reader or an advanced multi-mode model, Allsheng offers filter-based and monochromator detection systems to meet your needs. Choose between compact or full-featured options tailored to your lab’s applications and budget. With intuitive operation and scalable configurations, these readers support absorbance, fluorescence, and luminescence workflows. Discover the perfect fit for your research at Apex Scientific.

Explore our full range of laboratory equipment at Apex Scientific in South Africa. For expert guidance, read our Insights article: How to Select the Best Microplate Reader for Your Laboratory Needs.

Model	AMR-100	AMR-100T
Display	7-inch touch screen
Light Source	Quartz-halogen lamp 6 V 10 W
Wavelength Range	340 nm ~ 750 nm
Filter	8-position filter wheel, standard 4 filters: 405nm, 450nm, 492nm, 630nm; other filters optional
Read-out Range	0 ~ 4.000 Abs
Linearity	[0.000 ~ 3.000 Abs] R² ≥ 0.995
Resolution	0.001 Abs
Wavelength Accuracy	≤ ±2 nm
Absorbance Repeatability	[0.3 Abs) CV ≤ 0.3 %; [3.4 Abs) CV ≤ 1 %	[0,3) CV ≤ 0.3 %; [3,4) CV ≤ 1 %
Absorbance Stability	≤ 0.005 Abs [0.3 Abs); ≤ 2.0 % [3.4 Abs)	≤ ±0.005 A [0,2 Abs); ≤ 0.3% [2,3 Abs); ≤ 2.0% [3,4 Abs)
Absorbance Accuracy	≤ ±0.005 Abs [0.2 Abs); ≤ ±0.01 Abs [2.3 Abs); ≤ ±1.5 % [3.4 Abs)	≤ ±0.005 A [0,2 Abs); ≤ ±1% [2,3 Abs); ≤ ±1.5% [3,4 Abs)
Sensitivity/Detector	≥ 0.01 A/photodiode
Test Speed	6 s/96-well (fast mode); single wavelength < 15 s/96 well; dual wavelengths < 28 s/96 well (normal mode)
User Interface	Built-in software, touch screen input, external mouse
Incubator	–	RT + 4 ℃ ~ 50 ℃
Temperature Accuracy	–	@ 37 ℃: ±0.5 ℃
Temperature Uniformity	–	@ 37 ℃: ±0.5 ℃
Storage	1000 test records
Port	3 USB ports (for PC, printer, USB-disk)
Power Supply	AC 100-240 V, 50-60 Hz, 2 A
Dimension (W×D×H)	295 × 440 × 225 mm
Weight	10 kg	11 kg

SKU	Description
AS-16050-00	Allsheng AMR-100 Microplate Reader
AS-16060-00	Allsheng AMR-100T Microplate Reader

SKU	Description
AS-16051-01	Optical filter 340nm
AS-16051-02	Optical filter 380nm
AS-16051-03	Optical filter 405nm
AS-16051-04	Optical filter 415nm
AS-16051-05	Optical filter 450nm
AS-16051-06	Optical filter 492nm
AS-16051-07	Optical filter 540nm
AS-16051-08	Optical filter 570nm
AS-16051-09	Optical filter 578nm
AS-16051-10	Optical filter 590nm
AS-16051-11	Optical filter 595nm
AS-16051-12	Optical filter 630nm
AS-16051-13	Optical filter 650nm
AS-16051-14	Optical filter 690nm
AS-16051-15	Optical filter 470nm
AS-16051-17	Optical filter 510nm
AS-16051-18	Optical filter 520nm
AS-16051-19	Optical filter 532nm
AS-16051-20	Optical filter 546nm
AS-16051-21	Optical filter 560nm
AS-16051-22	Optical filter 562nm
AS-16051-23	Optical filter 600nm
AS-16051-24	Optical filter 620nm
AS-16051-25	Optical filter 646nm
AS-16051-26	Optical filter 663nm
AS-16051-27	Optical filter 700nm
AS-16051-28	Optical filter 750nm
AS-16051-51	Printer
AS-16051-52	Printer Paper
AS-16051-53	ABS optical performance validation board
AS-16051-54	Readerlt-I software
