Features of Multi Centrifuge Varispin 6:
- Wide Range of Application – Various rotor options for multiple purpose in different users.
- Various tubes available – Various tubes from 1.5ml to 100ml are available, suitable tube adapters can be selected.
- Silent Operation – Well-ballanced motor minimized vibration, which leads to the most silent operation
Technical Specification:
| Model | Varispin 6R | |
| Max. RPM | Angle Rotor 6,000rpm | Swing Rotor 4,500rpm |
| Max. RCF | 5,357 xg | 3,781 xg |
| Max. Capacity | 50ml x 8 | 100ml x 4 |
| Accel / Decel phase | 0 ~ 9 (10set) | 0 ~ 9 (10set) |
| Set Temp. | -10℃ ~ +40℃ ( 1℃ increments ) | -10℃ ~ +40℃ ( 1℃ increments ) |
| Ref. System | Non-CFC | Non-CFC |
| Noise Level | ≤60dB | ≤60dB |
| Set Time | 99 hour 59 min 59sec or continuous | 99 hour 59 min 59sec or continuous |
| Time Count | At set Speed or from starting | At set Speed or from starting |
| Program | 100 memory | 100 memory |
| Rotor ID | Automatic Recognition | Automatic Recognition |
| Display | 4.3” LCD Touch Screen | 4.3” LCD Touch Screen |
| Display message on screen | RPM, RCF, Time, Door open/close, Temp ACC, DEC, Rotor ID, Program, Comp. On/Off, Key lock | RPM, RCF, Time, Door open/close, Temp ACC, DEC, Rotor ID, Program, Comp. On/Off, Key lock |
| RPM Range | 400 to 6,000 rpm | 400 to 6,000 rpm |
| Available Rotor Quantity | 14 | 14 |
| Power Supply | AC 230V ± 10%, 50-60Hz, 1Phase | AC 230V ± 10%, 50-60Hz, 1Phase |
| Power Consumption | 1.8KW | 1.8KW |
| Dimension(W x D x H) | 636 x 611 x 334 mm (H:774mm with open lid) | 636 x 611 x 334 mm (H:774mm with open lid) |
| Weight (without rotor) | 67kg | 67kg |
Available Rotors:
| AL1615G | F15A-3 | F15A-5 | |||
 |
 |
 |
|||
| Fixed Angle Rotor ∠ 45′ 16 x 15ml Radius(mm) : 150.3 |
 |
 |
 |
 |
 |
| Volume (ml) | 3 | 5 | 10 | 15 | 15 Conical |
| Number per rack / rotor | 16 | 16 | 16 | 16 | 16 |
| Adaptor bore (mm) | 13.5 | 13.5 | 18 | 18 | 18 |
| Max. height for use(mm) | 130 | 152 | 136 | 136 | 136 |
| RPM | 4,000 | 4,000 | 4,000 | 4,000 | 4,000 |
| Radius (mm) | 130.3 | 148.7 | 150.3 | 150.3 | 144.8 |
| RCF | 2,331 | 2,660 | 2,689 | 2,689 | 2,590 |
| A850GC | F50CA-15C | |
 |
 |
|
| Fixed Angle Rotor ∠ 30′ 8 x 50ml Radius(mm) : 133.1 |
|
 |
| Volume (ml) | 15 Conical | 50 Conical |
| Number per rack / rotor | 8 | 8 |
| Adaptor bore (mm) | 17 | 30 |
| Max. height for use(mm) | 130 | 130 |
| RPM | 6,000 | 6,000 |
| Radius (mm) | 130.3 | 133.1 |
| RCF | 5,244 | 5,357 |
| S4100G | B100 | |||||||||
 |
 |
|||||||||
| S100T-1.5-6 | S100T-5-5 | S100T-10-4 | S100T-15-3 | S100T-15C-3 | S100A-50 | S100A-50C | S100A-85 | S100A-100 | ||
 |
 |
 |
 |
 |
 |
|
 |
|
||
| Swing Out Rotor Max. RPM : 4,000 Radius(mm) : 167 Max RCF : 2,987 |
 |
|
|
 |
|
 |
|
 |
|
|
| Volume (ml) | 1.5 | 5 | 10 | 15 | 15 Conical | 50 | 50 Conical | 85 | 100 | |
| Number per rack / rotor | 6/24 | 5/20 | 4/16 | 3/12 | 3/12 | 1/4 | 1/4 | 1/4 | 1/4 | |
| Adaptor bore (mm) | 11 | 13.5 | 16 | 17.5 | 17 | 29.5 | 30 | 38.5 | 44 | |
| Max. height for use(mm) | 130 | 130 | 130 | 130 | 133 | 130 | 133 | 130 | 130 | |
| RPM | 4,000 | 4,000 | 4,000 | 4,000 | 4,000 | 4,000 | 4,000 | 4,000 | 4,000 | |
| Radius (mm) | 164 | 164 | 164 | 164 | 167 | 164 | 167 | 164 | 164 | |
| RCF | 2,934 | 2,934 | 2,934 | 2,934 | 2,987 | 2,934 | 2,987 | 2,934 | 2,934 | |
| S2G-MTP | ||
 |
||
| Swing Out Rotor Max. RPM : 4,000 Radius(mm) : 112 Max RCF : 2,003 |
 |
 |
| Volume (ml) | MTP | DWT |
| Number per rack / rotor | 2/4 | 1/2 |
| Adaptor bore (mm) | ||
| Max. height for use(mm) | ||
| RPM | 4,000 | 4,000 |
| Radius (mm) | 112 | 112 |
| RCF | 2,003 | 2,003 |
Order Information:
| ITEM | DESCRIPTIONS | ORDER CODE | |
| Main Body | VARISPIN 6R | VARISPIN 6R, refrigerated, without rotor,AC 230V ±10% 50/60Hz, EU Standard plug | V6R-MB |
| Angle Rotor | AL1615G | 15ml x 24 fixed angle rotor with 15ml stainless steel sleeves (Max 4,000RPM) | V6R-AR1 |
| A850GC | 50ml Conical x 8 fixed angle rotor for conical tubes (Max 6,000RPM) | V6R-AR2 | |
| Swing Rotor | S4100G | 100ml x 4-wing swing rotor for round buckets (Max 4,500RPM) | V6R-SR1 |
| S2G-MTP | 2-wing micro plate swing rotor (Max 4,000RPM) | V6R-SR2 | |
