Features
- 304 stainless steel, mirror polishing processing, easy to clean and maintain.
- PID controller with over temperature alarm and timing function ensures precise and reliable control, also save more than 40% heating time.
- A big dual layer tempered glass on the door provides good observation.
- Door adjustment system with silicon door gasket ensures better vacuity.
Option
- KF25 Vacuum Port.
- LED lights on the door.
- Inert gas valve.
Specifications
| Model | DZF-6012 | DZF-6020
DZF-6022 DZF-6024 |
DZF-6050
DZF-6053 DZF-6055 DZF-6056 |
DZF-6030A
DZF-6032 DZF-6034 (Special for chemistry) |
DZF-6092
DZF-6094 DZF-6096 |
DZF-6123
DZF-6126 |
DZF-6213
DZF-6216 |
DZF-6030B
DZF-6050B DZF-6055B (Special for biology) |
|
| Electrical
Requirement |
AC220V 50HZ | ||||||||
| Controller | LED display | ||||||||
| Power Consumption | 400W | 700W | 1450W | 550W
850W 850W |
870W | 1500W | 1550W | 300W
650W |
|
| Temperature Range | RT-10~200℃ | RT-10~65℃ | |||||||
| Display Resolution | 0.1 | ||||||||
| Temperature Stability | ±1℃ | ||||||||
| Vacuum Degree | 133Pa | ||||||||
| Chamber Volume | 10L | 24L | 50L | 30L | 90L | 125L | 216L | 30L/50L | |
| Ambient
Temperature |
+5~40℃ | ||||||||
| Interior Dimension
(W×D×H)mm |
220×210×220 | 300×300×275 | 415×370×345 | 320×320×300 | 450×450×450 | 500×500×500 | 600×600×600 | 320x320x300
415x370x345 |
|
| Exterior Dimension
(W×D×H)mm |
500×375×410 | 605×490×450 | 730×560×550 | 630×510×490 | 740×610×591 | 790×660×641 | 890×760×741 | 610x510x490
730x560x550 |
|
| Shelves | 2(pcs) | 1(pcs)
2(pcs) 4(pcs) |
2(pcs)
3(pcs) 5(pcs) 6(pcs) |
1(pcs)
2(pcs) 4(pcs) |
2(pcs)
4(pcs) 6(pcs) |
3(pcs)-Independent temp. control
6(pcs) |
1(pcs)
2(pcs) 5(pcs) |
||
| Chamber Material | 304 Stainless steel | 316 SS | 304 Stainless steel | ||||||
